本机主要用于高精度,大尺寸长条半断分切,放卷、分切、收卷同步进行。既可以分切卷材产品,也可分切片材产品。精度高,效率高,损耗少,操作简单。
特 点:
HX-320BF半断分切机主要用于高精度,大尺寸长条半断分切,放卷、分切、收卷同步进行。既可以分切卷材产品,也可分切片材产品。精度高,效率高,损耗少,操作简单。
Feature:
This machine is mainly used for high-precision, half cutting for large-size, unwinding, slitting, rewinding simultaneously. It also can slit products in roll and products in sheet. High precision, high efficiency, low waste, easy to operate.
用 途:
适用于脚垫、硅橡胶、泡棉、扩散片、反射膜、双面胶、PET、PC、PE、绝缘纸、铜/铝箔、导电布、导电泡棉,各种胶粘制品等材料分切。
Application:
Slitting for car mat, silicon rubber, foam, diffuser, reflective film, double-sided adhesive tape, PET,PC,PE, insulation paper, copper/aluminum foil, conductive fabric, conductive foam and various of adhesive products.
机器视频:
型号 Model
HX-320BF
电压 Voltage
220V50HZ
动力 Power
1HP
分切速度 sliiting speed
0-60m/min
最大进料宽度max feeding width
320mm
最小分切宽度min slitting width
1mm
最大分切宽度max slitting width
分切精度Precision
±0.05mm
最大收料直径max winding diameter
350mm
外型(长*宽*高)machine size (L*W*H)
1500*1000*1000mm
净重 N.W.
350kg
